TRANSMISSION COOLERS

TUBE AND FIN TRANSMISSION COOLERS

Ultrasonically soldered for reliability
100% pressure tested at 150 psi for quality assurance
High efficiency turbulators in every tube for maximum heat dissipation
3/8" push-on fittings for quick and easy installation

Part #

Description

Application Thickness Width Length Price
41010 Light Duty Compact to Mid-Size cars (light duty) 3/4" 5" 12-3/4"

$50.54

41011 Medium Duty Full-Size Cars & Mini-Vans & SUVs
towing up to 2,500 lbs. (med. duty)
3/4" 7-1/2" 12-3/4" $50.54
41013 Heavy Duty SUVs, Vans and Pick-up Trucks
towing up to 5,000 lbs.
3/4"    7-1/2" 15-1/2" $63.19
41014 X-Heavy Duty Pick-up Trucks and Motorhomes
towing over 5,000 lbs.
3/4" 10"  15-1/2" $75.84


PLATE AND FIN TRANSMISSION COOLERS

Durable brazed aluminum construction
Easy to install - simple instructions included
33% more smaller than comparable tube and fin designs

Part #

Qty.

Towing
Class

Application Thickness Width Length Price
41019 1 Class I Compact to Mid-Size cars
towing under 2000 lbs.
3/4" 4" 11" $75.84
41020 1 Class II Full-Size Cars, Mini-Vans & SUVs
towing 2,000-3,500 lbs.
3/4"  5-3/4"  11" $82.17
41310 1 Class III SUVs, Vans and Pick-up Trucks
towing 3,500-5,000 lbs.
3/4" 7-1/4" 11" $101.14
41311 1 Class III+ Pick-up Trucks and Motorhomes
towing over 5,000 lbs.
3/4" 12" 11" $113.79
41312 1 Class V+ Pick-up Trucks towing
5th Wheels and Gooseneck Trailers
1-1/2" 11" 11" $151.74


TRANSMISSION COOLER ACCESSORIES
Part# Qty Description Price
41102 1 Transmission Hose & Remount Kit, 11/32" x 4-1/2' $13.86
41103 1 Metal Strap Mounting Kit  $11.33
41405 1 Nylon Tie Mount Kit (4 per bag)  $6.82

TRANSMISSION COOLER STARTER KITS
Part# Qty Description Price
41102 1 Transmission Hose & Remount Kit, 11/32" x 4-1/2' $13.86
41405 1 Nylon Tie Mount Kit (4 per bag)  $6.82
41410 1 1983 & newer Ford, Lincoln & Mercury Cars
Adapter Kit for Duckbill Style Line Fittings
$17.19
41411 1 1986-Prior Jeep, 1991 to Current FWD GM, 96 & Later GMC/Chevy Truck & Van
Adapter Kit 5/8"-18, Inverted S.A.E. Flare.
$19.49
41412 1 1987 and newer Jeep
Adapter Kit 5/8"-18, 45 degree S.A.E. Flare
$19.49
41413 1 1987 and newer Jeep, 1995 and later Dodge Truck & Vans
Adapter Kit for Quick disconnect style with rubber hose/metal line.
$19.49
41414 1 1985-1995 GM Astro and Safari Vans
Adapter Kit for 1/2"-20 Inverted Flare, full thread
$22.94
41415 1 1983 and newer Ford, Lincoln & Mercury Cars and Ford Trucks & Vans
Adapter Kit for Deep-Thread Style
$22.94
41416 1 1999 and Later Dodge Trucks
Adapter Kit for 9/16"-18 JIC 37 degree Flare
$19.49
41417 1 1987 & Later Ford Areostar, Explorer, Expedition, F Series Trucks & Rangers
Adapter Kit for 5/8"-18 Inverted Flare, recessed thread
$22.94
41418 1 1996-Up GMC
Snap-in Transmission Cooler Fitting
$14.89 `
41010 1 3/4" x 5" x 12-3/4" Light Duty Transmission Cooler $44.57
41011 1 3/4" x 5" x 15-1/2" Medium Duty Transmission Cooler $57.74
41013 1 3/4" x 7-1/2" x 15-1/2" Heavy Duty Transmission Cooler $72.00
41014 1 3/4" x 10" x 15-1/2" Heavy Duty Transmission Cooler $84.28
41020 1 3/4" x 7-1/2" x 11" Medium Duty Transmission Cooler $79.65
41310 1 3/4" x 9-3/4" x 11" Heavy Duty Transmission Cooler $103.44
41311 1 3/4" x 11-3/8" x 11" Extra Heavy Duty Transmission Cooler $109.19


OEM CUSTOM FITTING KITS


1986 prior Jeep, 1991 to current FWD GM, 96 and later GMC/Chevrolet Truck & Van

3/8" O.D. Line with a 5/8" wrench size fitting threaded into the radiator.
Male hosebarb threads into radiator or radiator fitting. Female hosebarb threads onto transmission line fitting.

Part# Qty Description Price
41411 1 Adaptor Kit for 5/8"-18 Inverted Flare, full thread. $16.39



1987 and newer Jeep
3/8" O.D. Line with a 3/4" wrench size S.A.E. flare fitting
Male hosebarb threads into the transmission line fitting. Female hosebarb threads onto radiator fitting.

Part# Qty Description Price
41412 1 Adaptor Kit for 5/8"-18, 45 S.A.E. Flare. $16.39



1987 and newer Jeep, 1995 and later Dodge Truck and Vans
Rubber hose with swedged sleeve connecting to a 3/8" steel line. Quick disconnect fitting is going to the radiator.
Rubber section of transmission fluid line must be cut. Hose splicer fittings are used to attach

Part# Qty Description Price
41413 1 Adaptor Kit for Quick disconnect style with rubber hose/metal line. $16.39



1985-1995 GM Astro and Safari vans.
Line snaps into fitting and is held in by a four-prong clip.
Male fitting threads into radiator. Female fitting threads onto trans line fitting.

Part# Qty Description Price
41414 1 Adaptor Kit for 1/2"-20 Inverted Flare, full thread. $17.65



1983 and newer Ford, Lincoln & Mercury Cars.
Uses plastic retainer to attach steel transmission line to 11/16" diameter hex fitting in radiator. Radiator end of fitting has 1/4" MPT.
Factory fitting remains attached to the transmission line. Male hosebarb threads into the radiator. Female hosebarb threads onto the transmission line fitting.

Part# Qty Description Price
41410 1 Adaptor Kit for Duckbill Style Line Fittings $13.86



1983 and newer Ford, Lincoln & Mercury Cars and Ford Trucks & Vans.
5/8" diameter, 3/4" long hex fitting in the radiator. Transmission line fitting is 1/2"-20 inverted flare with recessed internal threads.
Female hosebarb threads onto the transmission line fitting. Male hosebarb threads into radiator fitting.

Part# Qty Description Price
41415  1 Adaptor Kit for Deep-Thread Style $23.98



1987 and later Ford Aerostar, Explorer, Expedition, F Series Trucks & Ranger.
3/4" diameter, 13/16" long hex with recessed internal threads.
Female hosebarb threads onto the transmission line fitting. Male hosebarb threads into radiator fitting.

Part# Qty Description Price
41417 1 Adaptor Kit for 5/8"-18 Inverted Flare, recessed thread. $22.71



1999 and later Dodge Trucks.
Flare nut on trans line, male flare fitting in radiator.
Female hosebarb threads onto the radiator fitting, male hosebarb threads into the trans line fitting.

Part# Qty Description Price
41416 1 Adaptor Kit for 9/16"-18 JIC 37 Flare. $16.39



1996 and up GMC
Flare nut on trans line, male flare fitting in radiator.
Female hosebarb threads onto the radiator fitting, male hosebarb threads into the trans line fitting.

Part# Qty Description Price
41416 1 Snap-In Transmission Cooler Fitting $16.39
